The Nanosecond Laser System is a cutting-edge technological solution designed for precision-based applications requiring rapid pulses of laser energy within the nanosecond range. This advanced laser system operates at high speeds, emitting ultrashort pulses lasting in the nanosecond domain, enabling precise material processing, scientific research, and industrial applications. The system generates laser pulses with durations in the nanosecond range, ensuring rapid and precise energy delivery for various applications. It delivers high peak power within nanosecond pulses, allowing for intense and controlled energy output required for precise material processing and industrial applications.

Nanosecond Laser

5W-15W1064nm YAG Laser

Pulse Repetition Rate Range: 5kHz-10kHz
Pulse Width: ≤30ns@10kHz
Average Power﹥5W, 8W, 12W@10kHz >10W, 15W@CW
Average Power Stability: <3%RMS over 8 hours
TEM00(M2 <1.5)
Beam Divergence Full Angle: <2mrad
1/e² Beam Diameter: 1mm

15W-60W 355nm UV Nanosecond Laser

Average Output Power: 15W-60 W
Pulse Width: < 25 ns
Repetition Rate: 50 kHz – 200 kHz
Beam Quality M² < 1.2

3W/5W 355nm YAG Laser

355nm YAG UV laser is an efficient and versatile laser device with a wide range of applications. It uses Nd:YAG crystal as the laser medium and triple frequency doubling technology to convert the 1064nm infrared laser to a 355nm ultraviolet laser. 355nm UV laser has high energy density, a short wavelength, and unique optical effects. It is stable and reliable, making it suitable for microelectronics processing, material processing, scientific research, and medical cosmetology. The laser enables high precise and efficient processing, advancing technology and innovation in various industries.

2W-5W 532nm YAG Green Laser

532nm YAG green laser is an efficient and stable laser with a wide range of applications. It is obtained by frequency conversion of the 1064nm infrared laser using YAG crystal as the activator. The green laser has high energy density and good beam quality. It is efficient, stable, and has a narrow output width. The power and frequency can be adjusted and controlled easily. It is safe and reliable with multiple protection mechanisms. Applications include laser display, biomedicine, scientific experiments, and traffic signals. 532nm YAG green laser has provided reliable performance.

5W-15W 1064nm YAG Laser

Average Output Power: 5W-15W
Pulse Repetition Rate: 5kHz–10kHz
Pulse Width: <30ns@10kHz
Single Pulse Energy: Up to 1.2mJ
Beam Quality (M²): <1.2

20mJ/30mJ 351nm Laser

Encapsulation in hundred class ultra clean laboratory
Good beam quality(M²<1.3)
High stability for long term running, 24/7 industrial application
Compact structure and low power consumption

8W-35W Green Nanosecond Laser

>60W@600kHz, <42ns@500kHz
>60W@60kHz, <12ns@60kHz
Good beam quality(M² <1.2)
Can be customized for high frequency up to 600kHz

12W-50W IR Nanosecond Laser

Encapsulation in hundred class ultra clean laboratory
Good beam quality
High stability for long term running, 24/7 industrial application
Compact structure，concise interface and strong mechanical stability
Optional functions of operator lock and alarm setting
